25 Hz L1+L5 dual-band, multi-constellation GNSS receiver 3-axis magnetometer 3-axis gyroscope 3-axis accelerometer Ambient light sensor Temperature sensor

Position Velocity Heading Heel Pitch Data logging at 10 Hz

High contrast, sunlight-readable 160 degree viewing cone 4.4" transflective LCD screen 320x240 pixel resolution, 91 ppi Digits up to 90 mm height (landscape), 40 mm height (2 metrics, portrait mode) Optically bonded 1.1 mm Gorilla Glass Multi-layer anti-reflective (AR) coating Water-shedding hydrophobic coating RGB LED array

Run time: 100+ hours Integrated 4600 mAh rechargeable lithium-ion battery Qi-compatible wireless charging

256 MB integrated storage 100+ hours, depending on logging rate Log at 2, 5, or 10Hz

Countdown timer Shift tracking Stripchart view VMG

Atlas Edge - PREORDER

Name: Atlas Edge - PREORDER
Brand: Vakaros
SKU: vkedgebase
Price: 749.0 USD
Availability: InStock

find your edge.

SAIL | RIDE | FOIL

Love the power. Love the price.

We've heard you: sailors have asked for a more cost effective instrument: the Atlas Edge fills that void.

CHOICE OF CHAMPIONS

Atlas users are claiming titles around the globe, from Olympic medals to local races.

CONNECT WITH YOUR COMMUNITY

Share your sessions from Vakaros connect and join the Atlas family.

$749.00

Tax included.

PACKAGE INFO BELOW

Two Year Warranty

BASE:

- Atlas Edge

FREERIDE:

- Atlas Edge

- Board Fairing Mount

- VK Bucket Hat

DINGHY

- Atlas Edge

- VK Bucket Hat

- 30 min. Data Debrief with Vakaros Expert

CHAMPIONS:

- Atlas Edge

- Bucket Hat

- Data Debrief

- Invite to 2x Edge development technical calls with Vakaros team

Use collapsible tabs for more detailed information that will help customers make a purchasing decision.

Ex: Shipping and return policies, size guides, and other common questions.

SIMPLE TECH. ADVANCED RESULTS.

Pair next generation insights with a simple UI: enhance your performance on and off the water.

TECH SPECS

25 Hz L1+L5 dual-band, multi-constellation GNSS receiver
3-axis magnetometer
3-axis gyroscope
3-axis accelerometer
Ambient light sensor
Temperature sensor

Position
Velocity
Heading
Heel
Pitch
Data logging at 10 Hz

High contrast, sunlight-readable
160 degree viewing cone
4.4" transflective LCD screen
320x240 pixel resolution, 91 ppi
Digits up to 90 mm height (landscape), 40 mm height (2 metrics, portrait mode)
Optically bonded 1.1 mm Gorilla Glass
Multi-layer anti-reflective (AR) coating
Water-shedding hydrophobic coating
RGB LED array

Run time: 100+ hours
Integrated 4600 mAh rechargeable lithium-ion battery
Qi-compatible wireless charging

256 MB integrated storage
100+ hours, depending on logging rate
Log at 2, 5, or 10Hz

Countdown timer
Shift tracking
Stripchart view
VMG

"The Atlas is a huge part of my training: we use data and video to get better and push to the Games"

5x Formula Kite World Champion Daniela Moroz

For freeride

New metrics include airtime, speed runs, jump height and distance, and more. View your stats on live in a way other sensors can't support.

built for the future

The Atlas Edge supports RaceSense, the future in on-water race management. Your instrument is your gateway to automatic OCS calls,

More about RaceSense

FAQs

Absolutely! The Atlas Edge fully supports RaceSense for both RC and competitors with its internal suite of widgets. This means Atlas Edge users will be able to compete in RaceSense events but will NOT be able to see DTL.

We're working with both the entire Atlas family to use our Class Compliant modes to create legal profiles for the Atlas across the board. You can lock down the Atlas Edge to restrict its capabilities and comply with most class rules. It's always best to check with your class measurer, however, about legality.

The hardware for the Atlas Edge and A2 are super similar, and they're compatible with all the same mounts. Most of the key differences are functions. Here's a quick list of functions the Atlas 2 has that the Atlas Edge doesn't.

Distance to Line (TTL and TTB)
Backlight
Sensor support
